custom Mini UHF male to Nickel plated silver SMA female with rg174 coaxial cable assembly

FOB Reference Price:Get Latest Price
$0.80 - $2.80 / Piece | 5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
RY
Model Number:
RY-984357084
Number of Conductors:
1
Type:
Coaxial
Impedance:
50ohm
Cable type:
RG series,low loss cable
Application:
RF Device
Certification:
CE/ROHS/ISO9001
Plating:
Nickel or gold
NAME:
Mini UHF cable assembly
Cable length:
Optional
Frequency:
0-6ghz
Conductor:
tinned/slivered copper
Supply Ability
Supply Ability:
50000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
1pc/polybag packaging
Port
shanghai

 UHF cable assembly



Product Description

custom Mini UHF male to Nickel plated silver SMA female with rg174 coaxial cable assembly










Specification

ELECTRICAL DATA
Impedance
50 Ohm
Frequency range
DC-6Ghz
VSWR
1.3 max
Voltage
60V AC(rms)
Insulation Resisitance
500 M Ohm min.
Insertion Loss
0.3dB max. at 1.0 GHZ/0.5DB max. at 2.0 GHZ
MATERIAL DATA
Bodies
Brass--gold/nickel plating
Pin contacts
Brass--gold plating
Socket contacts
Copper-beryllium alloy--Au plating
Insulator
PTFE
Cable type
0.81mm,1.13mm,1.37mm,RG178,RG174,RG316,RG58,LMR195,LMR240,LMR400,Semi-rigid,semi-flexible,super flexible, Formable,etc
Application
smartphone,tablet PC,wifi antenna,GPS antenna, RF device etc
Temperature range
-40°C to +80°C/200°C





Feature

Our this product line features popular coaxial cable, RF connectors, RF cable and other high quality coaxial products such as SMA connectors, coax adapters, and tools.

RF Coaxial cable assemblies are available in 50 Ohm and 75 Ohm styles. In addition, We stocks hundreds of low loss 50 Ohm antenna RF cable assemblies, pigtails and bulk cable for all your wireless connectivity needs.

Coax interfaces include: BNC, SMA, TNC, Type F, RCA, SMB, MCX, MMCX, Type-N, and more. We carry coax RF connectors and tools such as cable strippers, coaxial crimp tools, compression tools, and pin crimp tools to accommodate all of your coaxial termination requirements.



Similiar Product
Company Information



.jpg





Company profile:

RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.
Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.
2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.
3. Fast Delivery Time :2~15 days, On-Time Delivery.
4. Good After-Sales Service: we could offer technical support or return service in short time.
5. 1 Year Warranty.
6. OEM/ODM service.
7. We are available with Alibaba Trade Assurance, you'll enjoy:
   •100% product quality protection
   •100% on-time shipment protection
   •100% payment protection for your covered amount
